receiver module designed for high-precision positioning and heading applications in UAVs, robotics, automation, machine control, and defense-grade navigation systems. Supplied by Xtragen Technologies Pvt. Ltd., this advanced OEM GNSS board delivers exceptional accuracy, robustness, and reliability even in the most challenging RF environments.

This receiver supports full GNSS constellations, including GPS, GLONASS, Galileo, BeiDou, QZSS, NavIC, and SBAS, with 544 hardware tracking channels, ensuring maximum satellite visibility and positioning availability. In dual-antenna mode, it provides sub-degree GNSS-based heading and pitch or roll, eliminating dependence on magnetic sensors or vehicle dynamics.

Powered by Septentrio’s patented GNSS+ technology suite, the AsteRx-m3 Pro+ offers industry-leading protection against signal disturbances:

• AIM+ for advanced anti-jamming and anti-spoofing
• APME+ for multipath mitigation
• IONO+ for ionospheric interference protection
• LOCK+ for superior tracking under vibration and shock

The module delivers RTK accuracy of up to 0.6 cm horizontally, with low latency (<10 ms) and update rates up to 100 Hz, making it ideal for real-time, mission-critical applications. Its ultra-low power consumption enables longer battery life and compact system designs.

Designed for easy system integration, the AsteRx-m3 Pro+ includes USB, Ethernet, multiple serial ports, RTCM, NMEA, and Septentrio Binary Format (SBF) support. It is compatible with RxTools software, Web UI, SDKs for Windows and Linux, and PPK workflows, allowing seamless configuration, monitoring, and post-processing.

With a compact footprint, industrial-grade operating temperature range (-40°C to +85°C), and compliance with CE, FCC, RoHS, WEEE, and ISO standards, this GNSS receiver is engineered for reliability in demanding environments.

Xtragen Technologies Pvt. Ltd. provides technical support, integration assistance, and bulk supply options for OEMs, system integrators, and government projects across India.
